Ventray Max 120 Juicer Usage Tips and Maintenance Guide

To unlock the full functionality of the Ventray Max 120 juicer and fully unleash its power, it’s essential to learn how to use and maintain it correctly. This guide will help you understand how to use it in the right way, share useful tips, and provide maintenance advice to keep your juicer lasting as long as possible. Let’s explore it together!

Getting Started: How to Use it Correctly

Step 1: Assemble the juicing bowl on the base. Put the juicing screw into the juicing bowl. Open the feed chute lid, and rotate it clockwise until it clicks.

Step 2: Wash fruits and vegetables. Due to the wide 4.7-inch feed chute, you can feed whole apples or large carrots easily. Cut fibrous items like celery into small pieces to prevent clogging.

Step 3: Close the feed chute lid (The feed chute lid must be closed completely for the machine to start). Then place juice cups and pulp cups.

Step 4: Power on the juicer and start juicing. Enjoy!

Useful Tips to Maximize Your Juicing Experience

1. Well-Prepared

• Wash Thoroughly: Remember to always wash fruits and vegetables well to remove dirt and pesticides.
• Remove Pits: Take out large seeds, hardcore, and tough items. For example, apple cores, mango pits, lemon seeds, etc.
• Cut into Small Pieces: High-fiber vegetables like celery should be cut into small pieces to prevent clogging.

2. Maximize Yield

• Push Gently: Use the included pusher to gently push the veggies, avoiding forceful pushing.
• Choose High-Water Content Fruits and Vegetables: For example, fruits such as watermelon, pears, honeydew, and kiwi can be easily squeezed to produce juice.

3. Maintain Fresh Taste

• Drink Immediately: Fresh juice is the most flavorful. Drink as fast as possible to ensure that no nutrients are lost.
• Proper Storage: If you have to store it, remember to keep the juice in the refrigerator immediately. Consume within 24 hours for the best taste and quality.

How to Disassemble & Clean

After using the juicer, it’s time to disassemble it.

Step 1: Remove the juice cup and pulp cup.

Step 2: Open the feed chute lid and rotate counterclockwise to disassemble the feed chute.

Step 3: Pull out the juicing screw and juicing bowl vertically.

Step 4: Use the included cleaning brush to clean.

Tips for Cleaning

1. Clean the compression silicone in the juicing bowl. First, turn the juicing bowl upside down for easier handling, push the compression silicone out with your thumb, and clean it with water. After cleaning, please put it back in the center hole. The flat side of the compression silicone should be inside, while the ribbed side should be outside the juicing bowl.

2. Use one side of the cleaning brush to remove any remaining pulp from the inside of the juicing screw. While rinsing with water, use the side with the brush head to clean the inside of the juicing screw.

3. After cleaning, dry all parts and store them in a dry, cool place.

Maintenance and Repair Suggestions

Useful Tips

1. Avoid juicing ice cubes, dry, and hard ingredients. Remove seeds from seeded fruit.

2. Only use the provided pusher to push; others may damage the juicer.

3. Do not run the machine continuously for more than 20 minutes. Excessive working time causes the motor to heat up and be damaged.

4. Avoid reusing juiced pulp; it can clog the ejection system.

5. Do not put in fruits soaked in wine, honey, sugar, etc. It causes the lid of the feed chute not to open.

Troubleshooting

1. If the machine fails to start, ensure the power cord is properly connected. Verify the feed chute is securely installed. Confirm the appliance is assembled according to the manual. If still unresolved, please contact customer service.

2. If the feed chute cannot be opened, check if the juicer cup contains excessive pulp residue. If yes, press the “on” button to discharge the residue. Inspect for hard objects stuck inside. If detected, press “R” to return them to the feeding chute. If unresolved, contact customer service. Do not attempt to force it open.

3. If the machine stops during the operation, check if overloaded or oversized ingredients were added. Press and hold the “R” button to eject ingredients, then chop them smaller before restarting. If unresolved, contact customer service.

4. If there’s leakage from the base of the juicing bowl, ensure the silicone sealing ring at the cup’s center is properly seated. If the seal is correctly installed, avoid overfilling ingredients, which may stretch the seal and cause leaks. If unresolved, contact customer service.

5. Minor vibration or slight deformation during operation is normal and not a malfunction. No action is required.

Key Takeaways

By following these useful tips and maintenance guides, you can make delicious, nutritious, and fresh juice without effort. Regular cleaning and maintenance will extend the life of your Ventray Max 120 juicer. Ready to upgrade your juicer and start a new journey? Explore more details and recipes at Ventray.com.
